1. Feature

1) The machine have Chinese or English version

2) Cover foil automated peel away device: Very convenient, and could make sure cover foil peel away smoothly and without jerking from the tape, which could effectively prevent components jump out of the tape and jam the machine.

3) 2 placement heads:2 components could be picked and placed at the same time

4) Place components on the correct footprints with 360 degree orientation & required precision.

5) Automatic vacuum detection function with warning, which could automatically recognize missing components.

6) Could mount for 0402 and IC components with required precision, without vision system. The self-developed laser positioning principle is quite effective.

7) Integrated operating system, no need to connect a separate computer. 8G SD Card would be big enough for you to setup hundreds of thousands programs.

8) Integrated type of feeders: No need to buy extra mobile feeder arrays to save cost.

9) Easy and simple editing & storing for programs, fast changeover from one placement program to another.

10) Online programming function.

11) Smart model, convenient transportation.

12) Working power 200W: Environmental protection and energy saving.

2.  Technical parameter
